Description

CHATTANOOGA 4 CHANNEL WIRELESS PROFESSIONAL STANDARD is a wireless 4 channels stimulator developed to treat standard indications of electrotherapy (Pain & Standard Rehab and Vascular).


Discover the MULTI-SESSIONS technology offered by WIRELESS PRO four channel devices. Four modules, two standard remotes and a smart docking station allow you to synchronize modules and remotes to manage several sessions independently at the same time.

Additional remotes/modules are optional.

You will no longer use a stimulator with four channels but separate stimulators which are managed independently.

Please note this product is available in select international markets; it is not available in the U.S. Contact us for more details.

Programmes

4 standard programmes categories:

  1. Rehabilitation I
  2. Pain I
  3. Vascular
  4. Conditioning I
  5. Standard programme configuration – 4CH – Multi-Sessions.
  6. WIRELESS TECHNOLOGY

Removes constraints for you and your patient. Gives your patient a total freedom of movement facilitating patient manipulations and allowing you to combine active exercise with electro stimulation for a better result.

MULTI-SESSIONS

  • Wireless 4CH STD and FULL only, the devices are delivered with 4 modules, 2 remotes and a smart docking station allowing the use to synchronize modules and remotes to manage independently several sessions at the same time. Additional remotes/modules are optional.

MUSCLE INTELLIGENCE TECHNOLOGY

  • 4 functions Mi-Scan, Mi-Tens, Mi-Range and Mi-Action are available on each module (4 modules delivered).

+ TENS OPTION

  • Select one programme and add TENS on other channels. This allows treatment of two different body parts, two patients simultaneously or combines TENS and NMES when this kind of stimulation is required.

SKIP

  • Manage the session time and move directly to the next phase (recovery) when needed.

AUTONOMY AND SPEED RECHARGE

  • Daily use autonomy and with the charger included in the kit, a full cycle of recharging will take a maximum of 1.5 hours.

KNOWLEDGE INSIDE

  • Electrode placements, programme parameters and programme explanation directly available in the remote control.

SOFTWARE

  • Create your patient and history list and create customized stimulation programmes.

WARRANTY

  • The warranty is for 3 years from the date of purchase.

WAVE FORM

  • Symmetrical biphasic 100% compensated



TECHNICAL SPECS

Channels 4
Constant Current Up to a resistance of Max 1300 Ohm/channel
Maximum Pulse Intensity 120 mA
Pulse Width 30 to 400 μs
Pulse Frequency 1 to 150 Hz
MDD Class IIa
IP Class IP22
Applied part Type BF Comply with safety tests: IEC 60601-1, IEC 60601-1-2, IEC 60601-2-10
Power Supplies Lithium polymer (LiPo) rechargeable 3.7[V] / ≥ 1500[mAh]
Remote Control Dimensions 105 x 66 x 19 mm
Module Dimensions 55 x 16 mm
Docking Station Dimensions 265 x 240 x 200 mm
Remote Control Weight 116 g incl. battery
Module Weight 62 g incl. battery
Docking Station Weight 2.4 kg
Applied part Type BF Comply with safety tests: IEC 60601-1, IEC 60601-1-2, IEC 60601-2-10

Chattanooga 4 Channel Wireless Professional Standard unit - NMES / TENS (2 remotes)

Regular price $1,600.00

MEDI-2532118-CH

Chattanooga 4 Channel Wireless Professional Standard unit - NMES / TENS (2 remotes)

CHATTANOOGA 4 CHANNEL WIRELESS PROFESSIONAL STANDARD is a wireless 4 channels stimulator developed to treat standard indications of electrotherapy (Pain & Standard Rehab and Vascular).


Discover the MULTI-SESSIONS technology offered by WIRELESS PRO four channel devices. Four modules, two standard remotes and a smart docking station allow you to synchronize modules and remotes to manage several sessions independently at the same time.

Additional remotes/modules are optional.

You will no longer use a stimulator with four channels but separate stimulators which are managed independently.

Please note this product is available in select international markets; it is not available in the U.S. Contact us for more details.

Programmes

4 standard programmes categories:

  1. Rehabilitation I
  2. Pain I
  3. Vascular
  4. Conditioning I
  5. Standard programme configuration – 4CH – Multi-Sessions.
  6. WIRELESS TECHNOLOGY

Removes constraints for you and your patient. Gives your patient a total freedom of movement facilitating patient manipulations and allowing you to combine active exercise with electro stimulation for a better result.

MULTI-SESSIONS

  • Wireless 4CH STD and FULL only, the devices are delivered with 4 modules, 2 remotes and a smart docking station allowing the use to synchronize modules and remotes to manage independently several sessions at the same time. Additional remotes/modules are optional.

MUSCLE INTELLIGENCE TECHNOLOGY

  • 4 functions Mi-Scan, Mi-Tens, Mi-Range and Mi-Action are available on each module (4 modules delivered).

+ TENS OPTION

  • Select one programme and add TENS on other channels. This allows treatment of two different body parts, two patients simultaneously or combines TENS and NMES when this kind of stimulation is required.

SKIP

  • Manage the session time and move directly to the next phase (recovery) when needed.

AUTONOMY AND SPEED RECHARGE

  • Daily use autonomy and with the charger included in the kit, a full cycle of recharging will take a maximum of 1.5 hours.

KNOWLEDGE INSIDE

  • Electrode placements, programme parameters and programme explanation directly available in the remote control.

SOFTWARE

  • Create your patient and history list and create customized stimulation programmes.

WARRANTY

  • The warranty is for 3 years from the date of purchase.

WAVE FORM

  • Symmetrical biphasic 100% compensated



TECHNICAL SPECS

Channels 4
Constant Current Up to a resistance of Max 1300 Ohm/channel
Maximum Pulse Intensity 120 mA
Pulse Width 30 to 400 μs
Pulse Frequency 1 to 150 Hz
MDD Class IIa
IP Class IP22
Applied part Type BF Comply with safety tests: IEC 60601-1, IEC 60601-1-2, IEC 60601-2-10
Power Supplies Lithium polymer (LiPo) rechargeable 3.7[V] / ≥ 1500[mAh]
Remote Control Dimensions 105 x 66 x 19 mm
Module Dimensions 55 x 16 mm
Docking Station Dimensions 265 x 240 x 200 mm
Remote Control Weight 116 g incl. battery
Module Weight 62 g incl. battery
Docking Station Weight 2.4 kg
Applied part Type BF Comply with safety tests: IEC 60601-1, IEC 60601-1-2, IEC 60601-2-10
